This listing is the complete Furrion FGR17G3MA2B-BG 17-inch three-burner range oven with black glass with silver handle finish, SKU 2023045674. It includes both a cooktop and an oven; the silver replacement handle shown in Service & Replacement Parts is a separate service item.
Confirm the exact appliance model, fuel and electrical supply, installation opening and clearances before ordering. Similar range names and finishes do not establish installation or service-part interchangeability.
Authorized Furrion® Dealer · 100% OEM Authentic Parts. Manufacturer specifications: CCD-0009304 identifies this exact model; the user and service manuals establish the SKU. The appliance diagram shows 21 7/16 in W × 16 1/16 in H × 21 3/4 in D; net weight is 55.8 lb. The oven is 1.24 cu ft with a 7,100 BTU oven burner; cooktop ratings are 8,000 BTU front and 6,500 BTU for each rear burner. Fuel is propane, ignition is piezo, and electrical supply is 12V DC. Furrion model and specification sheet. Appliance dimensions are separate from installation cutout and shipping dimensions. The nominal 17-inch designation is not a 17-inch-wide cabinet opening. The specification sheet lists a Flame Failure Device on each burner; this is not permission to operate the range while driving. CCD-0009304 prints 2022045674 in its cover SKU row; the exact model FGR17G3MA2B-BG and the user/service manual identity establish SKU 2023045674.
Features & Specifications
- Brand: Furrion
- ERVP SKU: 2023045674
- Manufacturer / cross-reference part: 2023045674
- Product family: Furrion complete RV range ovens
- Application: Complete FGR17G3MA2B-BG propane range oven
- Order check: Match the appliance label, fuel, power and installation dimensions.
Complete range and service parts
This is the complete FGR17G3MA2B-BG appliance. For a handle repair, the separate silver handle 2021124003 is documented for this exact model in Furrion CCD-0008217, printed page 7, callout T. Confirm the model before selecting any other service component.
Compare Furrion cooking appliances
The links below are catalog browsing options. They include different appliance types and do not establish drop-in installation or parts compatibility.
| Model / Part | Category | Best For | View Details |
|---|---|---|---|
|
® - 17" 3-Burner All Glass Gas Range with FFD - LED Knobs - Black Glass with Silver Handle - #2023045674 2023045674 |
Complete range oven | Complete FGR17G3MA2B-BG range oven | Current Product |
| ® - 3-Burner Gas RV Range with Flame Sense - 21", Glass Cover, Black on Black - #2023045676 2023045676 |
Oven | Other cooking appliance; verify type and installation requirements | View Details |
| ® - Greystone 17" Black Gas Range - 2N1 with FFD - Cast Iron Grate, Glass Top - #2023046466 2023046466 |
Oven | Other cooking appliance; verify type and installation requirements | View Details |
| ® - 3-Burner Gas RV Range with Flame Sense - 21", Glass Cover, Black on Black - #2023045676 2023045676 |
Oven | Other cooking appliance; verify type and installation requirements | View Details |
Tip: do not substitute across control generations, appliance sizes, finishes, refrigerant types, or model families unless the manufacturer documentation says the parts interchange.
Technical Specifications
| Product title | Furrion® - 17" 3-Burner All Glass Gas Range with FFD - LED Knobs - Black Glass with Silver Handle - #2023045674 |
| SKU | 2023045674 |
| Part number | 2023045674 |
| Product type | Complete three-burner propane range oven |
| Fitment caution | Model-specific; verify against your original label or parts diagram. |
What's Included
The complete FGR17G3MA2B-BG range oven is the appliance listed here. The specification sheet lists one oven rack and an optional drawer front; do not assume that an optional drawer front or installation accessories are included.
Compatible Models & Alternatives
Use the model-specific Service & Replacement Parts links for documented components. The comparison table contains other cooking appliances for browsing; it does not certify them as interchangeable. Do not infer fit from finish, nominal size or a product image.
Frequently Asked Questions
- Is this a complete range or a replacement component?
- This is the complete FGR17G3MA2B-BG range oven, SKU 2023045674, with black glass with silver handle finish. Silver handle 2021124003 is a separate service item.
- What are its appliance dimensions?
- The dedicated diagram gives 21 7/16 in W × 16 1/16 in H × 21 3/4 in D. These are appliance dimensions, not the required cabinet opening or shipping package.
- What are the burner ratings?
- The cooktop has one 8,000 BTU front burner and two 6,500 BTU rear burners. The separate oven burner is 7,100 BTU.
- What fuel and power does it require?
- The specification sheet lists propane fuel, piezo ignition and 12V DC electrical supply. Match the installation manual and appliance label.
- Which replacement handle is documented?
- Furrion CCD-0008217 printed page 7 callout T lists silver handle 2021124003 for FGR17G3MA2B-BG. Other components require their own exact-model evidence.
Why Buy from Elkhart RV Parts?
Elkhart RV Parts focuses on hard-to-find RV service parts and keeps listings organized around the details that matter: brand, SKU, part number, application, and fitment warnings. That makes it easier to order the right component the first time.
| Model | FGR17G3MA2B-BG |
|---|---|
| Sku | 2023045674 |
| Product type | Complete three-burner propane range oven |
| Finish | black glass with silver handle |
| Width (inches) | 21.4375 |
| Height (inches) | 16.0625 |
| Depth (inches) | 21.75 |
| Net weight (pounds) | 55.8 |
| Oven capacity (cu ft) | 1.24 |
| Oven burner (btu) | 7100 |
| Front cooktop burner (btu) | 8000 |
| Rear right cooktop burner (btu) | 6500 |
| Rear left cooktop burner (btu) | 6500 |
| Fuel type | Propane |
| Ignition type | Piezo igniter |
| Power supply | 12V DC |
| Glass cover | Two-piece folding |
| Grate | Matte enamel stamped |
| Oven rack | One included; three positions |
| Drawer front | Optional |
| Dimension basis | CCD-0009304 exact-model diagram and specifications; appliance dimensions, not cutout or shipping package. |
| Safety | Flame Failure Device (FFD) on each burner |
- Is this a complete range or a replacement component? This is the complete FGR17G3MA2B-BG range oven, SKU 2023045674, with black glass with silver handle finish. Silver handle 2021124003 is a separate service item.
- What are its appliance dimensions? The dedicated diagram gives 21 7/16 in W × 16 1/16 in H × 21 3/4 in D. These are appliance dimensions, not the required cabinet opening or shipping package.
- What are the burner ratings? The cooktop has one 8,000 BTU front burner and two 6,500 BTU rear burners. The separate oven burner is 7,100 BTU.
- What fuel and power does it require? The specification sheet lists propane fuel, piezo ignition and 12V DC electrical supply. Match the installation manual and appliance label.
- Which replacement handle is documented? Furrion CCD-0008217 printed page 7 callout T lists silver handle 2021124003 for FGR17G3MA2B-BG. Other components require their own exact-model evidence.
- Does the nominal 17-inch size mean a 17-inch-wide cutout? No. The appliance width is 21 7/16 inches. Use the exact model installation manual for the required cabinet opening, clearances and ventilation; do not size the opening by the nominal 17-inch name.
