The Dometic Analog Adapter Board (Part# 9610001568) is a critical control component for Dometic Brisk II and Penguin rooftop air conditioners. This OEM adapter board interfaces between your RV's analog thermostat and the AC unit's electronic controls, enabling proper temperature regulation and system operation. If your AC isn't responding to thermostat commands or cycles erratically, this adapter board is often the solution.
Key Features
- OEM Dometic Part: Genuine factory replacement ensures perfect fit and reliable performance
- Analog Thermostat Interface: Bridges analog wall thermostats to digital AC control systems
- Direct Replacement: Installs in place of failed original adapter boards with no modifications
- Brisk II & Penguin Compatible: Designed specifically for Dometic's popular rooftop AC models
- Restores Full Functionality: Returns proper temperature control and system cycling to your AC unit
Technical Specifications
| Part Number | 9610001568 |
| Component Type | Analog Adapter Control Board |
| Application | AC Control Interface |
| Compatible Systems | Dometic Brisk II, Dometic Penguin |
| Thermostat Type | Analog/Mechanical Thermostats |
Compatible Models
| Model Series | Description |
| Brisk II | All Dometic Brisk II rooftop air conditioners with analog thermostat control |
| Penguin | Dometic Penguin series rooftop AC units using analog thermostats |
Frequently Asked Questions
A: Common symptoms of a failed adapter board include AC not responding to thermostat adjustments, unit running continuously without cycling off, or no power to the AC despite the thermostat being on. If your analog thermostat clicks but the AC doesn't respond, this board is likely the culprit.
A: No, this adapter board is specifically designed for analog (mechanical) thermostats. If you have a digital thermostat, you'll need a different control board. Check your thermostat type before ordering—analog thermostats have a physical dial or slider, while digital ones have an LCD screen.
A: Installation requires accessing the AC unit's control box (typically inside the RV ceiling or in the rooftop unit itself) and replacing the existing board. Basic electrical knowledge is recommended. Always disconnect power before working on AC components, and take photos of wire connections before removal to ensure correct reinstallation.
A: The adapter board typically includes basic installation guidelines. For detailed instructions specific to your AC model, consult your Dometic Brisk II or Penguin owner's manual, or contact our parts specialists who can provide model-specific guidance.
Why Choose Elkhart RV Parts?
ElkhartRVParts.com specializes in hard-to-find Dometic RV air conditioning components like this analog adapter board. Located in Elkhart, Indiana—the RV capital of the world—we maintain deep inventory of genuine OEM Dometic parts that other suppliers don't stock. Our team knows Dometic AC systems inside and out, and we're here to help you identify the exact part you need. We ship fast from our Elkhart warehouse, getting your RV's climate control back up and running quickly. When you order from us, you're getting authentic Dometic quality backed by expert support from people who understand RV systems.
| Brand | Dometic |
|---|---|
| Product type | Analog Adapter Board |
| System type | AC Control |
| Compatible models | Brisk II, Penguin |
| Part number | 9610001568 |
| Oem | true |
| Installation type | Bolt-on |
| Dimensions | {"Length"=>"4.20\"", "Width"=>"4.00\"", "Height"=>"1.50\""} |
| Control type | Analog Thermostat |
| Function | Restores analog thermostat control functionality for RV air conditioning systems |
