✓ ElkhartRVParts.com - The Only Authorized Place for Elkhart Plastics RV Water Tanks
✓ 100% Verified Authentic OEM Grade Part
Premium Elkhart Plastics 32 Gallon RV Holding Tank - H1133
Upgrade your RV's waste management system with this premium 32-gallon holding tank from Elkhart Plastics. Engineered with heavy-duty black polyethylene and seamless rotational molding, this tank delivers reliable, leak-proof performance for black water or gray water storage in motorhomes, travel trailers, and RVs.
Key Benefits & Features
- Generous 32-Gallon Capacity - Perfect for extended trips and full-time RV living, providing ample waste storage for black water (toilet waste) or gray water (sink/shower waste)
- Heavy-Duty Black Polyethylene Construction - Manufactured from premium high-density polyethylene with 0.180" wall thickness for exceptional durability and impact resistance
- Seamless Rotational Molding Process - Advanced roto-molding technology creates a single-piece tank with uniform wall thickness and no weak spots, seams, or joints that could leak or fail
- UV-Resistant Black Color - Black polyethylene prevents algae growth and provides superior UV resistance for tanks mounted in exposed areas
- Standard 3" Outlet - Features a 3" outlet opening for fast, efficient waste drainage, compatible with most RV waste valves and sewer hose systems
- Blank Tank Configuration - Allows custom fitting installation to match your specific RV plumbing setup and requirements
- OEM-Grade Quality - Manufactured by Elkhart Plastics, a trusted name in RV tank manufacturing with decades of industry experience
Technical Specifications
- Capacity: 32 Gallons (121.1 liters)
- Dimensions: 26" L x 19" W x 21.25" H
- Part Number: H1133 / 3195
- Material: Black high-density polyethylene
- Wall Thickness: 0.180" (4.57mm)
- Weight: Approximately 25 lbs empty
- Manufacturer: Elkhart Plastics / Myers / Ameri-Kart
- Outlet Size: 3" (standard RV waste valve size)
- Color: Black
- Configuration: Blank tank (fittings not pre-installed)
- Use: Black water or gray water holding tank
- Construction: Seamless one-piece rotational molding
Perfect Applications & Compatibility
This versatile 32-gallon holding tank is ideal for a wide range of RV waste management applications:
- Class A, B, and C Motorhomes
- Travel Trailers and Fifth Wheels
- Black Water Tank Replacement (toilet waste)
- Gray Water Tank Upgrade (sink/shower waste)
- RV Renovations and Repairs
- Custom RV Builds and Conversions
- Horse Trailers with Waste Systems
- Mobile Homes and Park Models
- Replacement for Worn or Damaged Tanks
- Full-Time RV Living Applications
Why Choose This Elkhart Plastics Holding Tank?
Industry-Leading Quality: Elkhart Plastics has been manufacturing premium RV holding tanks for decades, with a reputation for quality and reliability that's trusted by RV manufacturers and owners nationwide. This tank meets or exceeds OEM standards.
Seamless Construction Advantage: The advanced rotational molding process creates a single-piece tank with uniform wall thickness throughout. Unlike welded or seamed tanks, there are no weak points where leaks can develop over time, ensuring long-lasting, leak-proof performance.
Built for the Road: The heavy-duty 0.180" wall thickness and impact-resistant polyethylene construction withstand years of road vibration, temperature changes, and regular use without cracking or failing. This tank is engineered to handle the demands of life on the road.
Optimal Capacity: 32 gallons provides the perfect balance between capacity and space efficiency for most RV applications, offering extended use between dump station visits without taking up excessive space.
Installation & Maintenance
This 32-gallon tank is designed to fit standard RV mounting configurations with its 26" x 19" x 21.25" dimensions. The blank tank configuration allows you to install custom fittings that match your specific RV plumbing system.
Installation Tips: At approximately 25 lbs empty, this tank is manageable for installation but will require proper support when full (32 gallons = approximately 267 lbs). Ensure your mounting location can support the full weight. Professional installation is recommended if you're not experienced with RV plumbing systems.
Manufacturing Note: The sealed hole on top of the tank is from the rotational molding manufacturing process. It's a venting hole used during tank creation and has no functional use for the end-user. This is normal and does not affect tank performance or integrity.
Maintenance: Use quality RV holding tank treatment to break down waste and control odors. Rinse tanks thoroughly after dumping to prevent buildup. Keep tanks at least 1/3 full when traveling to maintain proper sensor function. Inspect fittings and seals annually for signs of wear.
What's Included
- One Elkhart Plastics 32-gallon holding tank (H1133)
- Blank tank configuration (fittings not pre-installed)
Note: Fittings, mounting hardware, sensors, and plumbing connections are sold separately and should be selected based on your specific RV plumbing configuration.
Complete Your RV Waste System
Looking for different sizes or complementary products? Check out these related items:
- 29 Gallon Elkhart Plastics Holding Tank (45x15.5x12.375) - Slightly smaller capacity with slim profile
- 30 Gallon RV Holding Tank (54x22x8) - Alternative 30-gallon with long, low profile
- 35 Gallon RV Black Water Holding Tank (54x32x8) - Larger capacity for extended trips
- Universal Holding Tank Fittings Kit - Complete fittings with level sensors
- Lippert Flow Max Holding Tank Treatment - Premium waste treatment for odor control
Compare RV Holding Tank Options
Not sure which size is right for you? Here's how our Elkhart Plastics holding tanks compare:
| Model | Capacity | Dimensions (LxWxH) | Part Number | Best For | View Details |
|---|---|---|---|---|---|
| H1296 | 29 Gallons | 45" x 15.5" x 12.375" | H1296 | Slim profile, tight spaces | View Details |
| H866 | 30 Gallons | 54" x 22" x 8" | H866 / 1433 | Long, low profile install | View Details |
| H1133 (Current) | 32 Gallons | 26" x 19" x 21.25" | H1133 / 3195 | Balanced dimensions, standard install | You're viewing this |
| 4894 | 35 Gallons | 54" x 32" x 8" | 4894 / H867070 | Extended capacity, low height | View Details |
Choosing Tip: All tanks provide similar capacity, but dimensions vary significantly. Measure your available mounting space carefully—pay special attention to height clearance. The H1133's balanced 26x19x21 dimensions make it versatile for most standard RV installations!
Frequently Asked Questions
Q: Does this tank come with fittings installed?
A: No, this is a blank tank with no pre-installed fittings. This allows you to customize fitting placement for your specific application. Fittings can be purchased separately or we can provide a quote for custom fitting installation.
Q: Can I use this for both black water and gray water?
A: Yes! This tank is suitable for both black water (toilet waste) and gray water (sink/shower waste) applications. The black polyethylene construction is ideal for waste storage.
Q: What is the sealed hole on top of the tank?
A: This is a normal part of the rotational molding manufacturing process. It's a sealed venting hole used during production and has no functional purpose for the end-user. It does not affect tank performance or integrity.
Q: Will this fit my RV?
A: Please verify the dimensions (26" x 19" x 21.25") match your available space and that the 3" outlet location works for your setup. For help with fitment, use our AI Live Chat for personalized assistance.
Q: Is this tank odor-resistant?
A: The tank itself is made from non-porous polyethylene that won't absorb odors. For best odor control, use quality holding tank treatments and maintain proper ventilation in your waste system.
Q: How much does 32 gallons of waste weigh?
A: 32 gallons of waste weighs approximately 267 pounds (8.34 lbs per gallon). Ensure your mounting location and RV structure can support this weight plus the tank weight (approximately 25 lbs).
Q: What's the difference between black water and gray water tanks?
A: Black water tanks hold toilet waste, while gray water tanks hold sink and shower waste. This tank can be used for either application. The black color helps prevent algae growth in both applications.
Q: How do I maintain this holding tank?
A: Use quality RV holding tank treatment to break down waste and control odors. Rinse tanks thoroughly after dumping to prevent buildup. Keep tanks at least 1/3 full when traveling to maintain proper sensor function. Inspect fittings and seals annually.
Q: Can I install sensors in this blank tank?
A: Yes, the blank tank configuration allows you to drill holes and install sensors at the locations that work best for your setup. We recommend using our Universal Holding Tank Fittings Kit which includes level sensors.
Why Buy From ElkhartRVParts.com?
- ✓ Authorized Elkhart Plastics Dealer - 100% authentic parts guaranteed, never knockoffs or inferior substitutes
- ✓ Expert RV Parts Specialists - Our team knows RV waste systems inside and out, ready to help with fitment questions
- ✓ Fast Shipping - Ships from our Elkhart, Indiana warehouse—the heart of RV country—for quick delivery
- ✓ Competitive Pricing - Premium OEM-grade components at fair prices
- ✓ Trusted Nationwide - Relied upon by RV owners and professional technicians across the country
- ✓ 24/7 AI Live Chat Support - Get instant help with product selection, compatibility, and installation guidance
Ready to Upgrade Your RV's Waste Management System?
This premium Elkhart Plastics 32-gallon holding tank delivers the durability and leak-proof performance you need for reliable waste storage. With seamless construction, heavy-duty polyethylene, and OEM-grade quality, you can trust this tank to handle the demands of life on the road.
Need help choosing the right size or have questions about installation? Our AI Live Chat is available 24/7 to provide expert guidance on product selection, compatibility, and installation tips.
Ships fast from our Elkhart, Indiana warehouse - the heart of RV country! Order today and get back on the road with confidence.
| Material | Black polyethylene |
|---|---|
| Width (inches) | 19 |
| Height (inches) | 21.25 |
| Length (inches) | 26 |
| Capacity (gallons) | 32 |
| Wall thickness (inches) | 0.18 |
| Outlet diameter (inches) | 3 |
- What are the dimensions of the 32 gallon rv holding tank? The dimensions of the tank are 26 inches by 19 inches by 21 1/4 inches.
- What material is the rv holding tank made from? The tank is made from black polyethylene with a wall thickness of 0.180 inches.
- Does the 32 gallon rv holding tank come with fittings? No, the tank is sold as a blank tank without fittings. Fittings can be added based on a quote.
- Is the sealed hole on top of the tank functional? No, the sealed hole on top is a venting hole used during manufacturing and has no functional use for the end-user.
- How is the tank manufactured to ensure durability? The tank is made using a roto-molding process where high-density plastic is rotated and molded into a seamless shape with equal wall thickness, providing strength and durability.
