Furrion - Main Control Board for Arctic 15.6 cu. ft. 12V Refrigerator (FCR16DCASA-BG / -SS) - Part# 2026066404

This is the genuine Furrion main control board, part# 2026066404 — the main electronic control PCB for the Furrion Arctic 15.6 cu. ft. 12 volt side-by-side residential-style RV refrigerator, models FCR16DCASA-BG and FCR16DCASA-SS. Lippert catalogues it as "PCB MAIN FCR16DCASA CONTROL BOARD (NEW)", manufacturer reference C-FCR16DCASA-067.

Part number note — read this if you were quoted an older number. Part# 2026066404 is the current revision of this board and supersedes 2022111964 and manufacturer reference C-FCR16DCASA-031, per Lippert's own listing. If your service quote, dealer paperwork or a previous order shows 2022111964 or C-FCR16DCASA-031, this is the part that replaces it. Older price files and third-party listings are still circulating the retired numbers.

What's Included

• One (1) Furrion control board, part# 2026066404 / ref C-FCR16DCASA-067, with its aluminum heatsink and mounting hardware attached as shown in our photographs
• One (1) blade fuse fitted on the board, marked 40

Not included: wiring harnesses, door switches, temperature sensors, the LED display / control panel assembly, the compressor driver board, the enclosure or module cover, and installation instructions. Furrion does not ship a standalone instruction sheet with this board — the appliance user manual is linked below and hosted on our own site.

Do You Need This Part?

The Arctic 16 uses two separate boards, and they are not interchangeable. Work through this before ordering:

1. Confirm the appliance. The model label must read FCR16DCASA-BG (black glass) or FCR16DCASA-SS (stainless). This board is not for the Everchill or Greystone 12 V refrigerators.
2. Decide which board failed. This part (2026066404, ref C-FCR16DCASA-067, formerly C-FCR16DCASA-031) is the main control board that runs the display, door switches, sensors and 12 V distribution. The compressor driver board is a different part — Lippert C-FCR16DCASA-060, part# 2022128891. If the display and lights work but the compressor never runs, look at the driver board first.
3. Rule out the simple causes. A dead panel is usually caused upstream of the board. Per Furrion's troubleshooting table, "no display on the display panel" is caused by the appliance not being switched on, a discharged 12 V battery bank, a blown or defective fuse, or intermittent/broken DC wiring — check all four before condemning the board.
4. Check Low Power mode. If both temperature displays show "--" and the interior lights are off, the refrigerator is in Low Power mode, not faulty. Press and hold the Function button for 5 seconds to exit.
5. Compare the board itself. Pull your board and compare it to our photographs above. Ours is silkscreened "SE DC12 POWER CO…", UL file E123995, FR-4 94V-0, with a large aluminum heatsink, four gold pin-header arrays down the right edge, and connector positions labelled for four door inputs (FL_DOOR, FR_DOOR, RL_DOOR, RR_DOOR) and four sensor inputs (R_SNR, F_SNR, FD_SNR, BW_SNR), plus 5 V SEL / 12 V SEL selection jumpers.

Technical Specifications

Furrion does not publish board-level dimensions, pinouts or a component-level schematic for this PCB, and we will not reproduce figures we cannot trace to a Furrion document. If you need a physical dimension to plan a repair, ask us and we will measure a board.

Compatible Models

This list is exactly what Furrion's own manual and Lippert's listing for the superseded C-FCR16DCASA-031 show — we have not padded it. Always confirm against your own appliance label and manual. If your model number is not listed, send it to us rather than guessing and we will confirm whether this board serves it.

Appliance Reference Specifications

Useful for confirming you are working on the right refrigerator. From Furrion's user manual for FCR16DCASA-BG / -SS:

Installation Notes

• Disconnect the 12 V DC supply before opening the control enclosure. Areas of this board are silkscreened HIGH VOLTAGE / DANGER, and stored charge remains in the electrolytic capacitors after power-down.
• Furrion requires the refrigerator to run on a dedicated 12 V circuit rated minimum 20 A and maximum 40 A, not shared with any other equipment.
• The circuit must be fused appropriately for the wire gauge used, with the fuse within 18 inches of the DC 12 V power source. Furrion specifies a single blow fuse only.
• If voltage drop is a problem at the appliance, Furrion's remedy is to shorten the wire run and/or increase the wire gauge — not to raise the fuse rating.
• Photograph every connector before unplugging it. The board carries separate labelled positions for four door inputs and four sensor inputs, and swapping two identical-looking plugs will produce a fault that looks like a bad board.
• Check the 5 V SEL / 12 V SEL jumper positions on your original board and set the replacement to match before powering up.
• Board replacement is a task for a qualified RV appliance technician. Furrion's own step-by-step video for this refrigerator is PCB replacement on FCR16DCASA on Lippert's support site.
• Appliance user manual: Furrion Arctic 15.6 cu. ft. 12 V refrigerator user manual (IM-FHA00108 V5.0, 32 pages, PDF) — hosted here for free, no registration required.

Frequently Asked Questions

Is this a genuine OEM Furrion part?

Yes. This is the genuine Furrion / Lippert service board, part# 2026066404, manufacturer reference C-FCR16DCASA-067. It is not an aftermarket equivalent or a rebuilt board, and it carries Lippert's 1-year warranty term.

I was quoted part 2022111964 or C-FCR16DCASA-031. Is this the same board?

Yes. Lippert lists 2026066404 as superseding both 2022111964 and C-FCR16DCASA-031. The current manufacturer reference is C-FCR16DCASA-067. The retired numbers are still widely quoted, so if that is what you were given, this is your part.

What is the difference between this board and the compressor driver board?

This part is the main control board (2026066404 / C-FCR16DCASA-067) that handles the display, door switches, temperature sensors and 12 V distribution. The compressor driver board is a separate part, Lippert C-FCR16DCASA-060 / 2022128891, which drives the compressor itself. A dead display points at this board; a compressor that never starts while everything else works points at the driver board.

My display is completely dead. Is the board definitely bad?

Not necessarily. Furrion's troubleshooting table lists four causes of a dead display before the board: the appliance not switched on, a discharged 12 V battery bank, a blown or defective fuse, and intermittent or broken DC wiring. Also confirm the refrigerator is not simply in Low Power mode, which shows "--" on both displays with the interior lights off and is cleared by holding the Function button for 5 seconds.

Will this board fit an Everchill or Greystone 12 volt refrigerator?

No. It is specific to the Furrion Arctic FCR16DCASA-BG and FCR16DCASA-SS. Send us your model number and we will find the correct board for other units.

How do I tell whether the board I have is this part?

Not from its label — the factory labels on this board are traceability codes (DA000068203, WLA 00240, DC12V 456) and do not carry the Lippert part number. Match on your appliance model number, or send us a photo of your board and we will identify it.

Does it come with a wiring harness or door switches?

No. This is the bare board with its heatsink and the mounting hardware shown in our photographs. Harnesses, sensors, door switches and the display assembly are separate parts.

Why Buy From Elkhart RV Parts

We are in Elkhart, Indiana, at the center of the RV industry, and we specialise in the hard-to-find service parts that keep an appliance out of the landfill — boards, sensors, latches and hardware, sold against the exact OEM part number rather than a vague description. Our listings are built from the manufacturer's own documents, we host those documents ourselves so you do not have to hunt for them, and we tell you when a specification cannot be verified instead of inventing one. Ships from Elkhart, Indiana.

Sources

• Furrion Arctic 15.6 cu. ft. 12 V Side-by-Side Residential-Style Refrigerator User Manual, FCR16DCASA-BG / FCR16DCASA-SS — form IM-FHA00108 V5.0, document CCD-0005509 Rev 01-10-23, 32 pages. Source of the electrical requirements, troubleshooting table, Low Power mode reset and all appliance specifications above. Hosted on our own server.
• Lippert — PCB MAIN FCR16DCASA CONTROL BOARD (NEW), SKU 2026066404. Source of the current manufacturer reference C-FCR16DCASA-067, the supersession of 2022111964 and C-FCR16DCASA-031, the 1-year warranty term, country of origin and shipping carton dimensions.
• Lippert — Control PCB C-FCR16DCASA-031 / 2022111964, the superseded listing. Source of the FCR16DCASA-BG / -SS fitment.
• Lippert — Compressor Driver Board C-FCR16DCASA-060 / 2022128891. Source for distinguishing the two boards.
• Lippert Support — PCB replacement on FCR16DCASA Furrion refrigerator. Manufacturer replacement procedure.
• Lippert Plant 80 / Plant 39 part cross-reference supplied directly to Elkhart RV Parts by Lippert's Plant 80 management. Source of the dual-plant sourcing and the original "CONTROL PCB" catalogue description for the superseded number.
• Board markings, label codes, fuse marking, connector labelling and heatsink construction counted and read from Elkhart RV Parts' own photographs of this part, shown above.
