Slow-Roll Shower Door Install Guide

The Slow-Roll Shower Door from Irvine Shade is a space-saving, easy-to-use solution for your RV shower. This guide walks you through everything you need to install it quickly and correctly, with just a few basic tools. Whether you're upgrading or replacing an old door, follow the steps below to get a clean, secure fit.

What’s Included

• Slow-Roll Shower Screen Assembly (cassette with retractable screen)
• 2 Side Rails (pre-applied adhesive tape)
• 1 Bottom Track

• End Caps
• Installation Instructions right here online (no paper copy is included.  Paper is not interactive)

Tools Needed

• Phillips screwdriver
• Measuring tape
• Level
• Pencil
• Utility knife
• (Optional) Silicone sealant for extra water protection

Step-by-Step Installation

1. Preparation
   • Clean the shower opening so it’s free of dust and debris.
   • Double-check that the opening dimensions match the door assembly.
2. Install Side Rails
   • Hold the side rails vertically; mark screw-hole locations and drill pilot holes.
     Because each RV wall is different material. You will need to provide your own screws based on what you are drilling into
   • Peel the adhesive backing, align rails, press firmly, then fasten screws.
3. Install Bottom Track
   • Measure and trim the track (if needed) so it fits snugly between side rails.
   • Press the track into place; run a thin bead of silicone along the edges if desired.
4. Install Shower Screen Assembly
   • Choose which side you want the cassette mounted.
   • Align the cassette with the bottom track and side rail.
   • Secure it using the pre-drilled holes and supplied screws.
5. Attach End Caps
   • Snap end caps onto the tops and bottoms of both side rails and the cassette.
6. Test the Door
   • Fully extend the screen and latch it.
   • Release to confirm smooth retraction and proper alignment.

Maintenance Tips

• Wipe the screen with a damp cloth regularly.
• Inspect rails and screen for wear or damage each season.
• If retraction feels stiff, apply a silicone-based lubricant to the rails.

Need a visual? Watch the install video on YouTube.

Still have questions? Email us and our team will get you squared away.
