Swinging TV Mount
This extension swivel wall TV mount gives you a full range of viewing angles in your RV. With the versatile design and double-joint extension arm, you can bring the TV or monitor closer to you and swivel, swing and tilt into place.
- Double-joint extension arm extends up to 25"
- Swivels up to 350°
- Swings up to 180°
- Tilts 0-10.5°
- 25 lb. weight capacity
- VESA mounting patterns
- Double-joint TV mount
- Pull strap
- Installation hardware
- Installation instructions
Enjoy a full range of TV viewing angles in your RV with this versatile extension swivel wall mount. The double-joint extension arm lets you bring the TV or monitor closer to you. It easily swivels, swings and tilts to angle the TV or monitor into place. Secure your TV in place with a sturdy locking mechanism.
GET THE RIGHT ANGLE YOUR TV with a double arm that extends, swivels and swings
SAVE SPACE with sleek wall mount design
LOCK SECURELY IN PLACE for safe travel
DIMENSIONS
- Overall: 10.5″H x 14.75″W x 25″D
VESA MOUNTING PATTERNS
- 75×75
- 100×100
- 200×200*
OPTIONS
- Adapter plate* 200mm x 400mm
Click HERE for installation instructions.
| Tilt angle (degrees) | 0-10.5 |
|---|---|
| Swing angle (degrees) | 180 |
| Overall depth (inches) | 25 |
| Overall width (inches) | 14.75 |
| Swivel angle (degrees) | 350 |
| Overall height (inches) | 10.5 |
| Weight capacity (pounds) | 25 |
| Extension arm length (inches) | 25 |
| Vesa mounting pattern 1 (millimeters) | 75x75 |
| Vesa mounting pattern 2 (millimeters) | 100x100 |
| Vesa mounting pattern 3 (millimeters) | 200x200 |
- What is the maximum weight capacity of the morryde tv1-087h swinging tv mount? The TV mount has a maximum weight capacity of 25 pounds.
- How far can the double-joint extension arm of the tv mount extend? The double-joint extension arm can extend up to 25 inches.
- What range of motion does the morryde tv1-087h swinging tv mount offer? The mount swivels up to 350 degrees, swings up to 180 degrees, and tilts from 0 to 10.5 degrees.
- Which vesa mounting patterns are compatible with this tv mount? The TV mount supports VESA mounting patterns of 75x75, 100x100, and 200x200 mm.
- What items are included in the box with the morryde tv1-087h swinging tv mount? The box includes the double-joint TV mount, a pull strap, installation hardware, and installation instructions.
